Produkt Info:
600 Meters Control DistanceDSSS* and FHSS* hybrid spread spectrum, 16 channels pseudo-random frequency hopping, and QPSK* modulation ensures excellent anti-interference performance, highly constant, and stable transmission signal present on all 10 channels of R6DS. Up to 600 meters* range enables all possible RC fun.
- * Direct Sequence Spread Spectrum transmissions multiply the data by a "noise" signal. This noise signal is a pseudorandom sequence of 1 and -1 at a frequency higher than that of the original signal.
- * Frequency Hopping Spread Spectrum offers three main advantages: signals are highly resistant to narrowband interference, are difficult to intercept, and can share a frequency band with many types of conventional transmissions with minimal interference.
- * Maximum range is tested in an unobstructed area free of interference.
6/10 channels of SBUS/PPM and PWM signal output.
Adaptable models include Rotary Wing, Fixed Wing, Glider, Multicopter, Car, Boat, and Robot. Weight of 3.4g and small size of 25x15mm make the R6DS tiny enough even for racing drones and gliders.
Real-time Telemetry
Real-time telemetry RSSI information allow users to receive crucial information on the model's systems.
R6DS Receiver Specs:
- Size: 25x15mm
- Antenna Length: 90mm
- Weight: 3.4g
- Channels: 6 for PWM signal output, 10 for SBUS, PWM, PPM & PWM signal output.
- Signals: SBUS, PWM, PPM & PWM
- Operating Voltage: 3~6V
- Operating Current: 38-45mA @5V
- Frequencies Band: 2.4GHz ISM (2400MHz~2483.5MHz)
- Spread Spectrum Mode: DSSS & FHSS
- Section Precision: 4096, 0.25us per section
- Applicable Models: Helicopter, Fixed-wing, Glider, Multicopter, Car, Boat, Robot
- Control Distance: 600 meters in the air (Maximum range tested in unobstructed areas free of interference and may vary depending on local regulations).
- Compatible Transmitters: AT10II, AT10, AT9S Pro, AT9S, AT9
