Futaba T7PX Touch Panel Color LCD Wheel Radio
The 7PX leads the way to a new revolution in surface control, thanks to Super Response Mode, full telemetry capability and the R334SBS diversity receiver!T-FHSS SR Super Response makes the 7PX the fastest Futaba radio yet, to give drivers a more “locked-in” feel while racing. In addition, the 7PX offers the T-FHSS protocol, which allows full telemetry capability. This radio is also compatible with S-FHSS and FASST protocols, expanding receiver options tenfold.
The innovations don’t stop there. A 4.3" backlit LCD touch screen lets drivers access key features instantly, via intuitively designed menus. When it comes to features, an R334SBS diversity receiver, 40-model memory and updateable software are just the tip of the iceberg.
Up to 7 channels can be controlled and programmed (depending on the used receiver). Up to 5 telemetry sensors can be viewed on the main screen for real-time information. Traction control and over-rev functions have been added to complement the ABS function. The 7PX supports high-speed servos—drivers can change the conventional 1,520 µ to 760 µ for SR Mode. The 7PX also adapts the “Return” function to “Throttle,” so drivers can set it with more accuracy.
T7PX Overview & Features:
- 4-7 channels (if more then 4 channels you need to use S-FHSS receivers such as R2008SB)
- Futaba SR (Super Response) technology
- T-FHSS SR (Super Response), T-FHSS, S-FHSS and FASST (C2) protocols
- Large, backlit 4.3" LCD touch screen
- Full telemetry compatible (with a telemetry supported receiver). If you want to use more then 4 channels (with a S-FHSS receiver) no telemetry functions are available.
- 40-model memory
- Display button
- 15-character model names
- Throttle selection (50/50; 70/30; 100)
- 5 programmable mixes
- S.BUS servo programming editor
- R334SBS 2.4GHz diversity receiver with gold plated connectors
- 6 assignable push buttons
- Channels 5/6 and 7 feature reversing, end point adjustments, sub-trim, assignable brake mixing and ABS
- One dial
- Conditions
- 4WS mixing
- Tank mixing
- Brake mixing
- Gyro mixing
- Steering mixing
- Tilt mixing
- CPS mixing
- Roll out chart
- Gear ratio chart
- Battery use: 2-cell LiFe, 5-cell NiMH (with 2-cell LiPo set to "other" and set alarm at 7V)
- Driver preference menu
- Exponential
- 6 assignable digital trims
- Assignable switch/dial functions
- Servo reversing
- Servo monitor
- Up/down/integral timer (records up to 80 laps)
- Lap timer/memory
- Wheel/trigger (tension, position, angle) adjustments
- Model copy
- Software-updateable with a micro memory card (sold separately) or via Near Field Communication (NFC). Just open an app on your Android™ device and place it next to the radio to update!
- Micro memory card slot
- Voice message/audio earphone jack
- Built-in speaker
- Right/left hand operation
- 2-position switch
- 4 trigger sizes
- 7 mm throttle trigger adjustment
- 24 steering wheel angle positions
- Low battery alarm
- Auto power-off
- Return button
Transmitter Specifications:
- Type: 7-Channel FASST/S-FHSS/T-FHSS/T-FHSS SR
- Voltage: 6-7.4V
- Weight: 580 g
- Includes: R334SBS diversity receiver (with gold connectors), APA adapter, large wheel with rubber grip, LCD protection sheet, mini driver and manual
- Requires: 2S 6.6V LiFe or 5-cell NiMH Tx Battery
R334SBS Receiver Specs:
- T-FHSS SR & T-FHSS
- 4 Channels
- S.BUS2
- Diversity Antenna
- Gold plated connectors
- Length: 34 mm
- Width: 22.3 mm
- Height: 11.5 mm
- Weight: 7 g
- Extrernal antenna: 205 mm
Compatible Receivers:
- T-FHSS SR (4CH): R334SBS & R334SBS-E (telemetry not supported)
- T-FHSS (4CH): R334SBS, R334SBS-E, R324SBS, R304SB, R304SB-E (telemetry supported)
- S-FHSS (up to 7CH): R203GF (3CH), R204GF-E (4CH), R2104GF (4CH), R2008SB (7CH), R2006GS (6CH), R2106GF (6CH)
- FASST (C2): R614FS (4CH), R614FF-E (4CH), R604FS (4CH), R604FS-E (4CH)
Compatible Telemetry Sensors as of August 2017 (with an telemetry supported receiver):
- SBS-01T: Temperature sensor with a loop - perfect for an engine head etc
- SBS-01TE: Temperature sensor - perfect for attaching to a electric motor or esc etc
- SBS-01RM: RPM Sensor - needs an small (included) magnet to be installed in the flywheel etc
- SBS-01V: External Volt Sensor - measures up to 100V
- SBS-01C: Current Sensor - measures voltage and current flow
- SBS-01/02G: GPS sensors - detects the position and speed of the vehicle
- Castle Telemetry Link Adapter: makes it possible to log Castle Creations compatible ESC's in the transmitter
Servos with SR Mode settings:
- BLS671SV/SVi
- BLS571SV
- BLS471SV
- BLS371SV
- BLS373SV
- S9372SV
- S9373SV
- HPS-CB700
